Systems of Linear Equations.

It is forbidden to kill; therefore all murderers are punished unless they kill in large numbers and to the sound of trumpets, Voltaire

Recall

Definition. A vector $\vec{AB}$ is a geometric object or quantity that has both magnitude (or length) and direction. Vectors in an n-dimensional Euclidean space can be represented as coordinates vectors in a Cartesian coordinate system.

Definition. The magnitude of the vector $\vec{A}$, also known as length or norm, is given by the square root of the sum of its components squared, $|\vec{A}|~ or~ ||\vec{A}|| = \sqrt{a_1^2+a_2^2+a_3^2}$, e.g., $||< 3, 2, 1 >|| = \sqrt{3^2+2^2+1^2}=\sqrt{14}$, $||< 3, -4, 5 >|| = \sqrt{3^2+(-4)^2+5^2}=\sqrt{50}=5\sqrt{2}$, or $||< 1, 0, 0 >|| = \sqrt{1^2+0^2+0^2}=\sqrt{1}=1$.


Solving Systems of Linear Equations

In linear algebra, solving a system of linear equations can be efficiently done using matrices.

Consider a system of linear equations:

$\begin{cases} a_{11}x_1 +a_{12}x_2 + ···a_{1n}x_n = b_1 \\ a_{21}x_1 +a_{22}x_2 + ···a_{2n}x_n = b_2 \\ . \\ . \\ . \\ a_{n1}x_1 +a_{n2}x_2 + ···a_{nn}x_n = b_n \end{cases}$

It can be written or represented in matrix form as: AX = B, where:

  1. A is a n×n matrix known as the coefficient matrix.
  2. X is an n×1 column matrix (vector) of variables.
  3. B is an n×1 column matrix (vector) of constants.

Solving a system of linear equations expressed as AX = B involves finding or isolating the matrix X when we are given both matrices A and B.

To solve AX = B, follow these steps:

  1. Ensure A is non-singular. This means that the determinant of A is not zero (det(A) ≠ 0), then we can multiply both sides of the previous equation form A-1.
  2. Calculate the inverse of A.
  3. Multiply both sides of the equation by A-2: A-1(AX) = A-1B⇒[Matrix multiplication is associative, so we can regroup the terms:] (A-1A)X =[The product of a matrix and its inverse is the identity matrix I] A-1B ⇒ IX = A-1B ⇒X = A-1B.

Examples

$\begin{cases} x + y + z = 6 \\ 2y + 5z = -4 \\ 2x + 5y -z = 27 \end{cases}$

In matrix form, this is, $\Bigl(\begin{smallmatrix}1 & 1 & 1\\ 0 & 2 & 5\\ 2 & 5 & -1\end{smallmatrix}\Bigr)\Bigl(\begin{smallmatrix}x\\ y\\ x\end{smallmatrix}\Bigr) = \Bigl(\begin{smallmatrix}6\\ -4\\ 27\end{smallmatrix}\Bigr)$.

To solve for X, we need to calculate A-1.

  1. Calculate the determinant of A. det(A) = a(ei - fh) - b(di - fg) + c(dh - eg) = 1·(-27)-1(-10)+1(-4) = -27 +10 -4 = -21.
  2. Find the Cofactor matrix C. $C_{ij} = (-1)^{i+j} \times \text{minor}(A_{ij})$ and C = $\Bigl(\begin{smallmatrix}-27 & 10 & -4\\ 6 & -3 & -3\\ 3 & -5 & 2\end{smallmatrix}\Bigr)$
  3. Transpose the cofactor matrix to obtain the adjugate matrix adj(A): adj(A) = CT = $\Bigl(\begin{smallmatrix}-27 & 6 & 3\\ 10 & -3 & -5\\ -4 & -3 & 2\end{smallmatrix}\Bigr)$
  4. Calculate the inverse A-1: $A^{-1} = \frac{1}{\text{det}(A)} \times \text{adj}(A)$.
  5. Multiply A-1 by B to find X: X = A-1B = $\frac{-1}{21}\Bigl(\begin{smallmatrix}-27 & 6 & 3\\ 10 & -3 & -5\\ -4 & -3 & 2\end{smallmatrix}\Bigr)\Bigl(\begin{smallmatrix}6\\ -4\\ 27\end{smallmatrix}\Bigr) = \frac{-1}{21}\Bigl(\begin{smallmatrix}−27⋅6+6⋅(−4)+3⋅27\\ 10⋅6+(−3)⋅(−4)+(−5)⋅27\\ −4⋅6+(−3)⋅(−4)+2⋅27\end{smallmatrix}\Bigr) = \frac{-1}{21}\Bigl(\begin{smallmatrix}−162−24+81\\ 60+12−135\\ −24+12+54\end{smallmatrix}\Bigr) = \frac{-1}{21}\Bigl(\begin{smallmatrix}-105\\ -63\\ 42\end{smallmatrix}\Bigr) = \Bigl(\begin{smallmatrix}5\\ 3\\ -2\end{smallmatrix}\Bigr)$.

Therefore, The solution to our original system of equation is X = ⟨5, 3, -2⟩. This method provides a systematic way to solve systems of linear equations using matrix operations, making it a powerful tool in linear algebra.

$\begin{cases} x + y + z = 7 \\ 3x - 2y -z = 4 \\ x + 6y +5z = 24 \end{cases}$

In matrix form, this is, $\Bigl(\begin{smallmatrix}1 & 1 & 1\\ 3 & -2 & -1\\ 1 & 6 & 5\end{smallmatrix}\Bigr)\Bigl(\begin{smallmatrix}x\\ y\\ x\end{smallmatrix}\Bigr) = \Bigl(\begin{smallmatrix}7\\ 4\\ 24\end{smallmatrix}\Bigr)$.

To solve for X, we need to calculate A-1.

  1. Calculate the determinant of A. det(A) = a(ei - fh) - b(di - fg) + c(dh - eg) = 1⋅((−2⋅5)−(−1⋅6)) −1⋅(3⋅5−(−1⋅1)) +1⋅(3⋅6−(−2⋅1)) = 1⋅(−10+6) −1⋅(15+1) +1⋅(18+2) = 1⋅(−4) −1⋅16 +1⋅20 = −4 −16 +20 = 0. The matrix A is singular, so the system could either be inconsistent or have infinitely many solutions.

If A is singular (det(A) = 0), we cannot find A-1. Instead, we need to use other methods like row reduction to understand the nature of the solutions.

  1. Convert to Row Echelon Form. A matrix is said to be in row echelon form when all its non-zero rows have a pivot, that is, a non-zero entry such that all the entries to its left and below it are equal to zero.

Start with the augmented matrix: $\Biggl(\begin{smallmatrix}1 & 1 & 1 &\bigm| & 7\\ 3 & -2 & -1 &\bigm| & 4\\ 1 & 6 & 5 &\bigm| & 24\end{smallmatrix}\Biggr)$

  1. Eliminate the x terms from the second and third rows, R2 = R2 - 3R1 and R3 = R3 -R1: $\Biggl(\begin{smallmatrix}1 & 1 & 1 &\bigm| & 7\\ 0 & -5 & -4 &\bigm| & -17\\ 0 & 5 & 4 &\bigm| & 17\end{smallmatrix}\Biggr)$
  2. Eliminate the y term from the third row, R3 = R3 + R2: $\Biggl(\begin{smallmatrix}1 & 1 & 1 &\bigm| & 7\\ 0 & -5 & -4 &\bigm| & -17\\ 0 & 0 & 0 &\bigm| & 0\end{smallmatrix}\Biggr)$.

The final augmented matrix shows that we have a row of all zeros, indicating that the system is consistent (0x+0y+0z = 0 ↭ 0 = 0) and has free variables.

$\begin{cases} x + y + z = 7 (i) \\ -5y -4z = -17 (ii) \end{cases}$

-5y -4z = -17 (ii)⇒$ y = \frac{-17+4z}{-5}$⇒[Substituting y into the first equation (i)] $x + \frac{-17+4z}{-5} +z = 7$ ⇒[Multiply through by 5 to clear the fraction] $5x +17 -4z + 5z = 35 ⇒ 5x + z = 35-17 ⇒ z = 18-5x$

$ y = \frac{-17+4z}{-5} = \frac{-17+4(18-5x)}{-5} = \frac{-17+72-20x}{-5} = \frac{55-20x}{-5} = -11+4x$

The system has infinitely many solutions of the form ⟨x, 4x -11, -5x +18⟩.

$\begin{cases} x -3y + z = 4 \\ -x + 2y -5z = -4 \\ 5x - 13y +13z = 8 \end{cases}$

In matrix form, this is, $\Bigl(\begin{smallmatrix}1 & -3 & 1\\ -1 & 2 & -5\\ 5 & -13 & 13\end{smallmatrix}\Bigr)\Bigl(\begin{smallmatrix}x\\ y\\ x\end{smallmatrix}\Bigr) = \Bigl(\begin{smallmatrix}4\\ -4\\ 8\end{smallmatrix}\Bigr)$.

To solve for X, we need to calculate A-1.

  1. Calculate the determinant of A. det(A) = a(ei - fh) - b(di - fg) + c(dh - eg) = 1⋅(2⋅13−(−5)⋅(−13))−(−3)⋅(−1⋅13−(−5)⋅5)+1⋅(−1⋅(−13)−2⋅5) = 1·(-39)+3·12+1·3 = -39 + 36 + 3 = 0. The matrix A is singular, so the system could either be inconsistent or have infinitely many solutions.
  2. Convert to Row Echelon Form. A matrix is said to be in row echelon form when all its non-zero rows have a pivot, that is, a non-zero entry such that all the entries to its left and below it are equal to zero.

Start with the augmented matrix:

$\Biggl(\begin{smallmatrix}1 & -3 & 1 &\bigm| & 4\\ -1 & 2 & -5 &\bigm| & -4\\ 5 & -13 & 13 &\bigm| & 8 \end{smallmatrix}\Biggr)$

  1. Eliminate the x term from the second and third rows: R2 = R2 + R1 (Add row 1 to row 2): $\Biggl(\begin{smallmatrix}1 & -3 & 1 &\bigm| & 4\\ 0 & -1 & -4 &\bigm| & 0\\ 5 & -13 & 13 &\bigm| & 8 \end{smallmatrix}\Biggr)$
  2. R3 = R3 -5R1 (Subtract 5 times row 1 from row 3): $\Biggl(\begin{smallmatrix}1 & -3 & 1 &\bigm| & 4\\ 0 & -1 & -4 &\bigm| & 0\\ 0 & 2 & 8 &\bigm| & -12 \end{smallmatrix}\Biggr)$
  3. Eliminate the y term from the third row: R3 = R3 + 2R2 (Multiply row 2 by 2 and add to row 3): $\Biggl(\begin{smallmatrix}1 & -3 & 1 &\bigm| & 4\\ 0 & -1 & -4 &\bigm| & 0\\ 0 & 0 & 0 &\bigm| & -12 \end{smallmatrix}\Biggr)$

Identify Inconsistency. The third rows indicates 0x +0y + 0z = -12 ⇒ 0 = -12. This is a contradiction, which means the system of equations is inconsistent. Therefore, there are no solutions to this system.

Equations of planes

A plane in three-dimensional space can be thought of as a flat, two-dimensional surface that extends infinitely in all directions.

To define a plane mathematically, we need two things:

  1. A point on the plane, often denoted as $\vec{P_0}$ = (x0, y0, z0).
  2. A normal vector to the plane, denoted as $\vec{N} = ⟨a, b, c⟩$. This vector is perpendicular (orthogonal) to every vector that lies on the plane.

Given a point P0 and a normal vector $\vec{N}$, we can find the equation of the plane. Here’s how:

  1. Vectors in the plane. Any point P = (x, y, z) on the plane creates a vector $\vec{P_0P}$ with the point P0. This vector is given by $\vec{P_0P} = ⟨x -x_0, y - y_0, z - z_0⟩$.
  2. Perpendicularity Condition. The vector $\vec{N}$ is perpendicular to the plane, it’s also perpendicular to any vector that lies in the plane. Mathematically, this means that their dot product is zero: $\vec{P_0P}·\vec{N}=0$.
  3. Dot Product Calculation. The dot product is calculated: $⟨x -x_0, y -y_0, z-z_0⟩·⟨a, b, c⟩ = 0 ↭ a(x-x_0)+b(y-y_0)+c(z-z_0) =0$, and this is called the scalar equation of the plane.


General Form of the Plane Equation

The scalar equation of the plane can be rearranged into a more familiar form: ax + by + cz = d where d = ax0 + by0 + cz0, ⟨a, b, c⟩ = $\vec{N}$.

Solved exercises

  1. Understanding the Normal Vector. A normal vector to a plane is a vector that is perpendicular to the surface of the plane. $\vec{N} = ⟨1, 5, 10⟩$
  2. Point on the plane. Since the plane passes through the origin, the point we use is $P_0 = ⟨0, 0, 0⟩$.
  3. Equation of the plane. We use the fact that any point P on the plane must satisfy the condition that the vector from the origin (P0) to P is perpendicular to the normal vector the plane: $\vec{OP}·\vec{N} = 0 ↭ ⟨x,y,z⟩⋅⟨1,5,10⟩.$
  4. Calculating the dot product: x + 5y +10z = 0.


  1. Identify the normal vector of the plane. The normal vector $\vec{N}$ of the plane x +4y -2z = 5 can be directly obtained from the coefficients of x, y, and z in the plane equation, $\vec{N} = ⟨1, 4, -2⟩$. Recall that the normal vector is perpendicular to the plane.

  2. The line passing through the point P(2, -4, 3) and in the direction of $\vec{N}$ can be written using the point-direction form of the line equation. If $\vec{r_0}$ is the position vector of the point P and $\vec{d}$ is the direction vector (which, in our particular case, is the normal vector $\vec{N}$), the vector equation of the line is (illustration ii) $\vec{r(t)}=\vec{r_0}+t\vec{d} = \vec{r_0}+t\vec{N}$.

  3. Substitute the known values: $\vec{r(t)} = ⟨2, -4, 3⟩ + t⟨1, 4, -2⟩ = ⟨2+t, -4+4t, 3-2t⟩.$

    Rotation Matrices

In conclusion, the vector equation of the line passing through the point P(2, -4, 3) and perpendicular to the plane x +4y -2z = 5 is $\vec{r(t)}=⟨2+t, -4+4t, 3-2t⟩.$

  1. Understanding the Normal Vector. A normal vector to a plane is a vector that is perpendicular to the surface of the plane. $\vec{N} = ⟨1, 5, 10⟩$
  2. Point on the plane: $P_0 = ⟨2, 1, -1⟩$.
  3. Equation of the plane. We use the fact that any point P on the plane must satisfy the condition that the vector from P0 to P, $\vec{P_0P}$, is perpendicular to the normal vector the plane: $\vec{P_0P}·\vec{N}=0↭ ⟨x -x_0, y -y_0, z-z_0⟩·⟨a, b, c⟩$ ↭[Calculating the dot product] $a(x-x_0)+b(y-y_0)+c(z-z_0) = 0$
  4. Substitute the given values: 1(x-2) +5(y-1) +10(z+1)=0 ↭[Expand and simplify] x −2 +5y −5 +10z +10 = 0 ↭[Combine like terms] x +5y +10z +3 = 0 ↭[Rearrange the equation to standard form:] x + 5y + 10z = -3.

Notice that if we are given the equation of a plane in this form, we can quickly get our normal vector, namely $\vec{N} = ⟨1, 5, 10⟩$ or alternatively, if know our normal vector, we can write down the left-hand side of the plane’s equation, and we plug in P0 in the left-hand side to get the value of the right-hand side of the plane’s equation.

  1. Extract the Normal Vector from the Plane Equation. The equation of the plane is given as x +y +3z = 5. This is the scalar equation of the plane. From the plane equation x +y +3z = 5, we can extract the normal vector $\vec{N}$ that is perpendicular to the plane. Its components are given by the coefficients of x, y, and z in the plane equation: $\vec{N} = ⟨1, 1, 3⟩$
  2. Calculate the dot product of $\vec{v}$ and $\vec{N}$: $\vec{v}·\vec{N}$ =[Recall, $\vec{a}·\vec{b}=a_1b_1+a_2b_2+a_3b_3$] 1·1 + 2·1 + (-1)3 = 1 + 2 -3 = 0.
  3. To determine if $\vec{v}$ is parallel, perpendicular, or neither to the plane, we will interpret the dot product result of $\vec{v}$ and $\vec{N}$. If the dot product is zero, it indicates that $\vec{v}$ and $\vec{N}$ are perpendicular to each other. Since $\vec{v}$ is perpendicular to $\vec{N}$, and $\vec{N}$ is the normal vector to the plane, then $\vec{v}$ is parallel to the plane.

Rotation Matrices

  1. Determine two vectors in the plane. Since the plane passes through points Q, R, and S, then we can find two vectors $\vec{QR}= R−Q = ⟨−4−(−1),2−1,2−2⟩ = ⟨-3, 1, 0⟩$ and $\vec{QS} = S−Q = ⟨−2−(−1),1−1,5−2⟩ = ⟨-1, 0, 3⟩$ that lie in the plane.

  2. Calculate the Normal Vector to the plane. The normal vector $\vec{N}$ to the plane can be found by taking the cross product of $\vec{QR}$ and $\vec{QS}$

    $\vec{N} = |\begin{smallmatrix} \vec{i} & \vec{j} & \vec{k}\\ -3 & 1 & 0 \\ -1 & 0 & 3 \end{smallmatrix}| = 3\vec{i} +9\vec{j} + \vec{k} = ⟨3, 9, 1⟩$

  3. Determine the plane equation. Let P(x, y, z) be an arbitrary point P in the plane, the vector $\vec{QP} = ⟨x +1, y -1, z -2⟩$ lie in the plane, and therefore is perpendicular to $\vec{N}$. Therefore, their dot product must be zero: $\vec{N}·\vec{QP} = 0 ↭ ⟨3, 9, 1⟩·⟨x +1, y -1, z -2⟩ = 0$ ↭[Calculate the dot product:] 3(x+1)+9(y-1)+(z-2) = 0 ↭[Simplify the equation:] 3x +3 +9y −9 +z −2 = 0 ↭ 3x + 9y + z = 8. Hence, 3x + 9y + z = 8 is the plane that passes through Q, R, and S.
